ASME Y14.24 – Types and Applications of Engineering Drawings
This Standard defines the types of engineering drawings most frequently used to establish engineering requirements. It describes typical applications and minimum content requirements. Drawings for specialized engineering disciplines (e.g. marine civil construction optics etc.) are not included in this Standard.
Y14.24 is a replacement of Y14.24M.
Product Details
- Published:
- 10/23/2020
- ISBN(s):
- 9780791873397
- ANSI:
- ANSI Approved
- Number of Pages:
- 93
- File Size:
- 2 files 5.3 MB
- Redline File Size:
- 2 files 12 MB
- Note:
- This product is unavailable in Ukraine Russia Belarus
