ASME Y14.47 – Model Organization Practices
This Standard establishes a framework for organizing a three-dimensional (3D) model and other associated information within the context of a product definition data set hereafter referred to as data set for the purpose of conveying a product definition that enables a model-based enterprise (MBE). This Standard contains no requirements pertaining to drawing graphic sheets. The framework defines a common practice to improve design productivity and to deliver consistent data content and structure to consumers of the data to facilitate common exchange interfaces.
Product Details
- Published:
- 06/06/2023
- ISBN(s):
- 9780791875513
- ANSI:
- ANSI Approved
- Number of Pages:
- 38
- File Size:
- 1 file 8.1 MB
- Product Code(s):
- N1942Q N1942Q N1942Q
- Note:
- This product is unavailable in Ukraine Russia Belarus
